Every 5 minutes for 40 seconds and the fan is switched on at the minimum speed. If the ambient temperature is
still TA-TS> 2 ° C, the fan stops and the device waits for another 5 minutes and so on, otherwise the control
resumes as described above
Timing
The maximum duration is 24h with increase of 0,5h from 0h to 10 hours and an increase by 1h after 10h. Once
the timing is started, the indicator lights up on the display.
• Timing OFF: you can activate this option only when the device is ON. The unit will automatically turn off
after the set time has elapsed, from 0,5h to 24h.
• Timing ON: you can activate this option only when the unit is OFF. The unit will automatically turn on
after the set time has elapsed, from 0,5h to 24h.
When the unit (by remote control) is switched ON / OFF after the program has been entered, the timing and
sleeping functions are deleted.
Sleeping
The sleeping function can be activated in AUTO, cooling, dehumidification and heating mode.
When activated, the fan operates only at minimum speed and the SLEEP wiring on the remote controller
display activates.
This function operates as follows:
• In cooling: the temperature increases by 1 ° C after one hour and again by 1 ° C after another hour.
• In heating mode: the temperature is reduced by 2 ° C after one hour and again at 2 ° C after another
hour.
After 7 h, temperature setpoint is restored to original value.
Air flow direction.
The stepper motor rotates the vanes from 0 ° (fully closed) to 145 ° (fully open), counter clockwise. If SWING
function is activated on the remote control, the vanes oscillate continuously between 145 ° and 65 °
13.4 OPERATING LIMITS
Ambient temperature between 5 ° C and 40 ° C - humidity between 0 and 90% non-condensing.
Water temperature between 9 ° C and 90 ° C in winter and between 5 ° and 20 ° C in summer.
Maximum operating water pressure 1.6 MPa (approx. 16 bar)
