Comfosplit IKARO HW – User and Installer manual EN
© Ideal Clima - Page 53 of 68
Open the front panel:
correct panel opening
wrong panel opening
At the sides of the front panel (one right and one
left), there are two recesses. Through them
rotate upward the panel until this will stop with a
click.
Do not completely remove the panel. removal
of the panl maye cause damage to the hinges.
Extract the air filters
Push gently upwards each filter, this removing it from the two tabs that hold it.
Pull filters down to remove them completely.
