Ideal-Standard Easybox Slim Series User Manual

2
63 - 73
40 - 50
58 - 68
47 - 57
144
G 1/2
G 1/2
G 1/2
Ø185
28
37
75
G 1/2
151
200
220
A5877AA circular escutcheon shower valve
shown with valve-box, trim & mounting bracket.
63 - 73
40 - 50
58 - 68
47 - 57
144
G 1/2
G 1/2
185
G 1/2
185
28
37
G 1/2
151
200
220
75
A5880AA square escutcheon shower valve.
shown with valve-box, trim & mounting bracket
Inlets & Outlets are threaded G1/2“.
The escutcheon plate can oat 10mm
between min & max markers thus per-
mitting mounting depth to vary.
Inlets & Outlets are threaded G1/2“.
The escutcheon plate can oat 10mm
between min & max markers thus per-
mitting mounting depth to vary.
