IDEAL Evomax 30 - EXTENSION KITS (100-150 MODELS); COMPONENTS FOR 100-150 MODELS

EXTENSION KITS
13EVOMAX - MULTILINE FLUE KITS
EXTENSION KIT COMPONENTS FOR 100-150 MODELS [UIN 210269]
12
11
1
2
3
4
5
8
8
8
9
10
6
7
POS. QTY. DESCRIPTION
1 1 ADAPTER CONCENTRIC PP 100/150 + MP
2 1 AIR INLET GRILL AL 150-100 H=85
3 1 EXTENSION PP 100x500
4 1 VALVE PP 100-150
5 1 REDUCER EXC. PP 150-100
6 1 ELBOW SHORT PP 100 90°
7 1 COLLECTOR PP 200x610 1x100 45°
8 3 LOCKING CLIP 100
9 1 LOCKING CLIP 150
10 1 LOCKING CLIP 200
11 1 WALL BRACKET 100 RAL-9016
12 1 WALL BRACKET AL 200 + WALL PLATE
Dn 100
