IDEAL Vogue S15

4
vogue system boiler -
Installation and Servicing
general
Vogue 15 18 26 32
Gas supply 2H - G20 - 20mbar
Gas Supply Connection 22mm copper compression
Injector Size (mm) 3.40 3.35 4.30 4.80
Flow Connection Central Heating 22mm copper compression
Return Connection Central Heating 22mm copper compression
Flue Terminal Diameter mm (in) 100 (4)
Average Flue Temp-Mass Flow Rate ºC (g/s) 72ºC (6 g/s) 67ºC (8 g/s) 70ºC (11 g/s) 70º (14 g/s)
Maximum Working Pressure (Sealed Systems) bar (lb/in
2
) 2.5 (36.3)
Electrical Supply 230 V ~ 50 Hz.
Power Consumption W 83 92 102 117
Fuse Rating External : 3A Internal : 4A Time Delay
Water content Central Heating litre (gal) 1.1 (0.24) 1.5 (0.33) 1.8 (0.41) 2.2 (0.48)
Packaged Weight kg (lb) 37.7 (83) 38.0 (84) 40.9 (90) 41.1 (91)
Maximum Installation Weight kg (lb) 31.9 (70) 33.1 (73) 34.4 (76) 35.9 (79)
Boiler Casing Size Height mm (in) 740 (29.1)
Width mm (in) 445 (17.5)
Depth mm (in) 330 (13)
Heat Exchanger Weight without Burner KG 6.0 7.3 8.2 9.5
Table 1 - General Data
Note. Gas consumption is calculated using a
caloric value of 38.7 MJ/m
3
(1038 Btu/ft
3
) gross
or 34.9 MJ/m
3
(935 Btu/ft
3
) nett
To obtain the gas consumption at a different
caloric value:
a. For l/s - divide the gross heat input (kW) by
the gross C.V. of the gas (MJ/m
3
)
b. For ft
3
/h - divide the gross heat input (Btu/h)
by the gross C.V. of the gas (Btu/ft
3
)
c. For m
3
/h - multiply l/s by 3.6
Key to symbols
GB = United Kingdom IE = Ireland (Countries of destination)
PMS = Maximum operating pressure of water
C
13
C
33
C
53
* = A room sealed appliance designed for connection via ducts to a
horizontal or vertical terminal, which admits fresh air to the burner
and discharges the products of combustion to the outside through
orices which, in this case, are concentric. The fan is up stream of
the combustion chamber. (*Note. C
53
covers optional high level and
balconly ue kits only.)
I
2H
= An appliance designed for use on 2nd Family gas, Group H only.
* The value is used in the UK Government’s Standard Assessment Procedure (SAP) for energy rating of dwellings. The test data from
which it has been calculated have been certied by a notied body.
Boiler Input : Max. Min.
15 18 26 32 15 18 26 32
Boiler Input ‘Q’ Nett CV kW 15.1 18.1 26.1 32.1 3.0 3.6 5.2 6.4
(Btu/h) 51,500 61,800 89,100 109,500 10,200 12,300 17,700 21,800
Gross CV kW 16.8 20.1 29.0 35.6 3.3 4.0 5.8 7.1
(Btu/h) 57,200 68,500 98,800 121,600 11,400 13,600 19,700 24,200
Gas Consumption m
3
/h 1.559 1.869 2.695 3.314 0.310 0.372 0.537 0.661
(ft
3
/h) 55.1 66.0 95.2 117.1 11.0 13.1 19.0 23.3
Boiler Output :
Non Condensing kW 15.0 18.0 26.0 32.0 3.0 3.6 5.2 6.4
70
o
C Mean Water temp. (Btu/h) 51,200 61,400 88,700 109,200 10,200 12,300 17,700 21,800
Condensing kW 16.2 19.3 27.9 34.3 3.2 3.9 5.6 6.8
40
o
C Mean Water temp. (Btu/h) 55,100 65,900 95,300 117,200 11,000 13,100 19,000 23,400
Seasonal efciency* SEDBUK 2005 91 91.1 91.1 91.1 n/a
Seasonal efciency* SEDBUK 2009 88.9 89.3 89.3 89.3 n/a
NOx Classication Class 5
Table 2 - Performance Data - Central Heating
