74
BOILER SEALING PANEL REPLACEMENT
1. Refer to Frames 45 & 46.
2. Refer to Frame 53.
3. Remove the old seal from the casing.
4. Fit the new seal ensuring correct location
over the xing pins and the material is fully
located within the casing.
5. Reassemble in reverse order.
6. Check the operation of the boiler. Refer to
Frames 32-35.
3
SERVICING
