IDS X Series Training V2.3 | Keypad Configuration
37
Location 243: Keypad ID
Enter this location physically on the keypad that you want to know the ID for.
Location 251 to 258: Keypad Options
Location Type: Bitmap
Each keypad can be set with the following options:
Option
Default
Action
Description
1
ON
The keypad will timeout
back to its default partition
after it has been used to
view another partition
If a keypad is made global, i.e. The keypad will be able to view
other partitions on the system. This option will automatically
return the keypad to its home partition which was programmed
into location 240
2
OFF
Keypad sleep mode
If this is enabled, the keypad will switch all its LEDs off after the
time programmed into location 22. Press any key to wake it up.
3
OFF
Global keypad status
If this is enabled the keypad can view any partition on the
system. This option ties in with option 1.
4
OFF
Show all Zones
If the keypad is set to global this option determines if the user
sees all zones, ON or only the zones that belong to the partition
5
OFF
Partition Menu
Shows all partitions if any of the following keys are pressed:
1-Quick Arm Key, 5-Stay Arm Key, 6-Stay and Go Key
6
OFF
Stay Menu
This option will ask for a profile number when the stay key,[5] is
pressed to arm in the stay profile
Exercise:
Configure keypad 1, to be a global keypad with the partition menu active
Instructions
Key presses
Enter the location for keypad 1
[2][5][1] [*]
Option 3 must be enabled
[3] [*]
Enable partition menu
[5] [*]
Exit the location
[#]
