IDS X Series Training V2.3 | Triggering Outputs
47
The X-Series alarm panel has 5 physical outputs on the main board, each expander has 2 and the X64
system can have up to 6 expanders. Each of the possible 8 keypads has an output. Below shows the
number assigned to each of the available outputs.
Number
Physical Outputs
Number
Physical Outputs
00
Disabled
13
Zone expander 4 output 2
01
Onboard output 1
14
Zone expander 5 output 1
02
Onboard output 2
15
Zone expander 5 output 2
03
Onboard output 3
16
Zone expander 6 output 1
04
Onboard output 4
17
Zone expander 6 output 2
05
Onboard output 5
34
Keypad 1 output
06
Zone expander 1 output 1
35
Keypad 2 output
07
Zone expander 1 output 2
36
Keypad 3 output
08
Zone expander 2 output 1
37
Keypad 4 output
09
Zone expander 2 output 2
38
Keypad 5 output
10
Zone expander 3 output 1
39
Keypad 6 output
11
Zone expander 3 output 2
40
Keypad 7 output
12
Zone expander 4 output 1
41
Keypad 8 output
When allocating an output to an event, an action must also be entered so that the system knows what to
do when triggered.
The action can be either a pulse or latch as discussed before. Below are the values for the actions.
Value
Output Action
ACTION
00
Set Output High (Set)
From 0V to 12V
01
Set Output Low (Reset)
From 12V to 0V
02
Pulse Output High
From 0V to 12V back to 0V
03
Pulse Output Low
From 12V to 0V back to 12V
When entering the value into the location follow the following steps:
1. Enter the output number that is to be triggered. [0][5]
2. Then enter the action to be performed. [0][2]
3. Only once the output number and the action have been entered press [*]
Outputs can be triggered by many different events and we will discuss the most common first.
Location 380: Clear Programmable Onboard Outputs on Disarm
Location Type: Bitmap
Any outputs enabled in this location will be reset when the alarm system is disarmed.
The onboard outputs are 1 to 5.
Default: OFF
Location 381 to 386: Clear Programmable Zone Expander Outputs on Disarm
Location Type: Bitmap
Any outputs enabled in this location will be reset when the alarm system is disarmed.
The zone expander outputs are:
Expander
1
2
3
4
5
6
Output
6
7
8
9
10
11
12
13
14
15
16
17
Default: OFF
