Triggering Outputs | IDS X Series Training V2.3
Location 389: Clear Programmable Keypad Outputs on Disarm
Location Type: Bitmap
Any outputs enabled in this location will be reset when the alarm system is disarmed.
The keypad outputs are:
Keypad
1
2
3
4
5
6
7
8
Zone No.
34
35
36
37
38
39
40
41
Default: OFF
Partition dependant events:
Location Type: Extended
There is a sub-location for each of the 8 partitions.
Loc
Event
Description
390
Close Programmable Output
Enter the output and action to be performed when the alarm is away
armed
391
Stay Close Programmable Output
When the alarm is armed in the stay mode, someone is staying on the
premises and internal zones are automatically bypassed
392
Open Programmable Output
Open means disarmed from either away or stay armed
393
Cancel Programmable Output
By disarming the partition an output can be turned off
394
Alarm Restoral Programmable Output
This is when a device has triggered and comes back to the normal
working state
395
Bypass Programmable Output
When a zone is disabled using the bypass key [9]
396
Forced Arm Programmable Output
If forced arm has been enabled and zones have been automatically
bypassed by the system to allow the panel to arm
397
Zone Tamper Programmable Output
If tamper has been enabled on a zone and the tamper switch on the
device is triggered
398
Zone Tamper Restoral Programmable
Output
When the tamper switch goes back to normal
399
Zone Shutdown Programmable
Output
If enabled and a zone does get bypassed
400
Zone Shutdown Restoral
Programmable Output
When the zone is un-bypassed at the auto test time if enabled to do
so
401
Keypad Panic Programmable Output
When the panic on the keypad is pressed
402
Keypad Fire Programmable Output
When the fire button on the keypad is pressed
403
Keypad Medical Programmable
Output
When the medical button on the keypad is pressed
404
Keypad Lockout Programmable
Output
If someone randomly presses keys and all parameters are met in
locations 20 and the keypad options menu (251 to 258) the keypad
will lock for the time specified in location 21
405
Duress Programmable Output
A duress code can be programmed into the system to mimic a user
code but will send a duress (panic) signal to the control room
406
Verifies Cross-Zone Trigger
Programmable Output
This output when programmed will trigger when an alarm is caused by
zones that are cross zoned. I.e. The number of triggers in the time
allocated is exceeded.
407
Burglary Programmable Output
Triggered when the alarm is armed and a zone is triggered
408
Panic Programmable Output
If any panic event is triggered
409
Fire Programmable Output
If a fire zone is triggered
410
Tamper Zone Programmable Output
If a zone is set to be of the zone type tamper
