IDS X Series Training V2.3 | Triggering Outputs
49
The following events do not need an action as they either follow an the event or are preprogramedaction.
Loc
Event
Description
411
Siren Programmable Output
Follows the dedicated siren output in every way
412
Strobe Programmable Output
Will set the output until a valid user code is entered
413
Chime Programmable Output
The output triggers when a chime zone is violated
414
Arm Follow Programmable Output
The output mimics the arm LED on the keypad
Note: When programming output 411 to 414, enter an output number only, as they mimic
other devices or actions.
Exercise: When the fire button on keypad 1, in partition 1, is pressed output 4 will pulse
Instruction
Key presses
Enter location 402
[4][0][2][*]
We are working in partition 1
[1][*]
The rule is output first then the action: output 4 then pulse
[0][4][0][2][*]
Exit location
[#]
Zone triggered outputs
A zone can be set to trigger an output when it is violated. If the zone is a zone that will only trigger when
the alarm is armed, then it will only trigger the output when all conditions are met. For example, an instant
zone will only trigger when the system is armed, but a 24-hour zone is always active, therefore, even if
the system is unarmed and the zone is triggered the output will trigger.
Location 415 to 422: Zone triggered outputs
Location Type: Extended
[Installer Code] [*] [4] [1] [5] [*] [Output No.] [*] [Output] [Action] [*]
Location
Zones
Locations
Zones
Locations
Zones
[415]
1 to 8
418
25 to 32
421
49 to 56
416
9 to 16
419
33 to 40
422
57 to 64
417
17 to 24
420
41 to 48
Data format: 0000
Valid Range: 0000 - 4103
Default: 0000
Globally triggered outputs
Location Type: Extended
These events do not depend on a partition but are system related.
Loc
Sub-
loc
Event
Description
423
1
AC Fail Programmable Output
By default the system monitors the 16V AC and will trigger
these outputs if there are any changes
2
AC Restore Programmable Output
3
Low Battery Programmable Output
The battery is monitored constantly
4
Low Battery Restore Programmable
Output
5
Auto Test Programmable Output
The system can be set to do a test at different intervals as
programmed into location 32
6
Download Programmable Output
When someone has connected to the alarm via the
download software
7
Siren Tamper Programmable Output
If siren monitoring is enabled and the siren goes missing
8
Aux 12V Trouble Programmable
Output
The 12V output on the panel is monitored constantly
