Configuring pulse length | IDS X Series Training V2.3
Loc
Sub-
loc
Event
Description
424
1
Reserved
2
Bus-wired Peripheral Tamper
Programmable Output
This is any device that connects to the system via the
communication bus
3
Bus-wired Peripheral Fail
Programmable Output
If the actual communication bus fails
4
Box Tamper Programmable Output
The alarm panel has a 2 pin connector that can be
connected to a switch to monitor the door of the panel box
5
Dedicated Panic Programmable
Output
Onboard next to zone 8 is a dedicated panic connector for
panic buttons
6
Communication Fail Programmable
Output
If the system cannot communicate and deliver an event via
phone after the number of tries programmed into location 47
7
Telephone Line Tamper
Programmable Output
The telephone line voltage is monitored and if this changes
then the output will trigger
8
Telephone Line Restore
Programmable Output
Set this to restore the output of option 7 if it was set to latch
Loc
Sub-
loc
Event
Description
425
1
RF Jam
If a signal is detected that interferes with the receiver a jam
will be logged and an output can be triggered and reset
when the jamming signal stops
2
RF Jam Reset
3
RF Supervision Fail
Each device is set to send a signal, either every 90min or 12
hours to confirm it is still available. If the system does not
receive the signals a supervision fail is logged
4
RF Detector Battery Low
When the wireless device detects that its battery voltage is
low it will inform the system and the system can set the
output to warn the occupants and restores when battery is
replaced
5
RF Detector Battery Restore
6
RF Receiver Battery
If the receiver‟s battery goes low an output can be triggered
and reset when restored
7
RF Receiver Battery restore
Loc
Sub-
loc
Event
Description
426
1
Wired Zone Expander Low Battery
Programmable Output
When a powered expanders battery voltage drops below
11V a low battery will be reported
2
Wired Zone Expander Battery
Restore Programmable Output
Once the battery is recharged a restore will be reported
3
Fire Sensor Power Programmable
Output
Fire sensors need to be reset when they have been
triggered. This option allows the system to reset the device
4
Dual Reporting Programmable
Output
When the system has been set to dual reporting and the
second number is dialled, this option will trigger the output
Configuring pulse length
The pulse duration can be lengthened if needed.
Location 428: Onboard Outputs Pulse Length
Location Type: Extended
Each of the five onboard outputs can be lengthened or shortened.
[Installer Code] [*] [4] [2] [8] [*] [Output No.] [*] [m] [m] [s] [s] [*]
Data format: mmss
Valid Range: 0000 – 5959
Default: 0002
