IDS X Series Training V2.3 | Event Reporting Codes
53
Location 571 Global Split Reporting
Location Type: Bitmap
Location 572 Global Split Reporting
Location Type: Bitmap
LED
On/Off
Action
Explanation
Split
Reporting
Option
Default
1
ON
Bus-wired peripheral
tamper reporting
Any device connected on the keypad bus is
tampered with this option will send a report
9
OFF
2
ON
Bus-wired peripheral fail
reporting
A device on the keypad bus fails and stops
communicating a report is sent
10
OFF
3
OFF
Bus-wired peripheral low
battery reporting *
If a device is powered by a battery because
of a power failure and the battery has
reached a critical level a low battery signal
is sent
11
OFF
4
ON
Wireless Detector Battery
Low
When a wireless device‟s battery needs
replacing a battery low signal will be sent
12
OFF
5
OFF
Wireless Detector
Supervision fail
If a device stops communicating after a set
amount of time a supervision failure is sent
13
OFF
6
OFF
Wireless Receiver Signal
Jammed
When a signal is detected that could block
signals from the wireless detectors a jam is
reported
14
OFF
7
OFF
Wireless Detector RSSI
Low
RSSI is the monitoring of signal strength
from detectors and if the signal drops
below 20% a message will be sent to alert
the security company
15
OFF
8
ON
AC Restored
After AC is restored a message can be sent
16
OFF
LED
Default
Action
Explanation
Split
Reporting
Option
Default
1
ON
AC fail reporting
After the wait time set in loc?? The AC failure will be
reported
9
OFF
2
OFF
Communication fail
reporting
If the system cannot report a failure to report
message is sent
10
OFF
3
ON
Telephone line tamper
reporting
The alarm monitors the voltage on the telephone
line and if that it goes missing a tamper is reported
11
OFF
4
ON
Siren fail reporting
The siren output monitors the load on the output
and if it goes missing then a tamper is reported
12
OFF
5
ON
Panel low battery fail
reporting
When AC is off and the battery voltage drops to
10.5V a battery low signal is sent, warning that the
system is close to shutting down
13
OFF
6
ON
Enable aux 12V fuse
fail reporting
If a short circuit or too much current is drawn from
the auxiliary 12V the fuse will shut off and send a
signal warning of a problem
14
OFF
7
OFF
Installer Reset
Required
If installer reset is enabled in loc.211 to 218 and the
alarm is triggered the system will not arm until the
installer code is entered. This alerts the security
company of this
15
OFF
8
ON
Box tamper reporting
The alarm has an input that monitors a switch that
monitors if the housing that it is in is opened
16
OFF
