Event Reporting Codes | IDS X Series Training V2.3
Location 573 Global Split Reporting
Location Type: Bitmap
LED
Default
Action
Explanation
Split
Reporting
Option
Default
1
OFF
Comms Restored
When the system is able to communicate
after a failure a restoral is sent
9
OFF
2
OFF
Comms Tamper
Restore
If the lines went down and when they start
working again a restore is sent
10
OFF
3
OFF
Siren Restore
If the siren went missing and is reconnected
a restore will be sent
11
OFF
4
OFF
Battery Restore
After a battery low is reported and the
battery is changed or charged a restore will
be sent
12
OFF
5
OFF
Aux 12V Restored
After a short circuit or too much current
being drawn is fixed the fuse will restore
and send a signal
13
OFF
6
OFF
Installer Reset restored
After an installer reset required condition is
reset a signal will be sent
14
OFF
7
ON
Box tamper restored
When the box that the system is housed is
closed a restore is sent
15
OFF
8
ON
Bus device tamper
restored
When the device on the keypad bus that
was tampered is restored a signal will be
sent
16
OFF
Location 574 Global Split Reporting
Location Type: Bitmap
LED
Default
Action
Explanation
Split
Reporting
Option
Default
1
OFF
Bus device comms
restored
When a device has stopped communicating on
the bus and when the fault is corrected and
communication is restored a signal is sent to
confirm this.
9
OFF
2
OFF
Bus device battery
restored
A device that reported a low battery on the bus will
send a restore when the battery voltage is full and
report the restoral condition
10
OFF
3
OFF
Wireless detector
battery restored
Once the wireless devices battery is changed it
will respond by sending a restore
11
OFF
4
OFF
Wireless detector
supervision restored
When a device starts communicating after being
marked as missing by the system a supervision
restoral is sent
12
OFF
5
OFF
Wireless receiver jam
restored
After detecting a strong signal that could cause
wireless devices from communicating is switched
off a restoral will be sent
13
OFF
6
OFF
Wireless detector RSSI
low restored
A device that recorded a low signal recovers and
the signal comes up to an acceptable level a
restoral will be sent
14
OFF
7
ON
Dedicated Panic
The X-Series has a dedicated panic onboard and
if this is triggered a panic signal will be sent
15
OFF
8
ON
Test Report
The alarm can be configured to send a test report
every 6 hours to every 14 days
16
OFF
