10.3 Teach mode
10.3.1 Setting of the sampling rate
The sampling rate indicates the time after which a new result of
measurement is provided and the outputs are updated�
The switching frequency is typ� approx� 1/3 of the sampling rate�
► Select [TEAC], then press [SET] and keep pressed until [WAIT] is
displayed�
> [rATE] and [rEPr] are displayed alternately�
► When [rATE] is displayed: Press [SET] until the preset measured
sampling rate value flashes�
► Enter a value incrementally by pressing [SET] once�
► Confirm with [MODE/ENTER]�
> [WAIT] is displayed while the repeatability [rEPr] is calculated�
> The sampling rate [rATE] and the repeatability [rEPr] are displayed
alternately�
10.3.2 Setting of the repeatability
► Select [TEAC], then press [SET] and keep pressed until [WAIT] is
displayed�
> [rATE] and [rEPr] are displayed alternately�
► When [rEPr] is displayed: Press [SET] until the preset repeatability
value flashes�
► Enter value incrementally by pressing [SET] once�
► Confirm with [MODE/ENTER]�
> [WAIT] is displayed while the sampling rate [rATE] is calculated�
> The sampling rate [rATE] and the repeatability [rEPr] are displayed
alternately�
10.3.3 Table repeatability and accuracy
Values for sampling rate 5 Hz
Distance
in [mm]
Repeatability Accuracy
white
90 % remission
grey
18 % remission
white
90 % remission
grey
18 % remission
200���1000 ± 6,5 mm ± 7,5 mm ± 32 mm ± 40 mm
1000���2000 ± 8 mm ± 9,5 mm ± 33 mm ± 40 mm
2000���3000 ± 17 mm ± 19 mm ± 42 mm ± 50 mm
3000���3500 ± 23 mm ± 25 mm ± 50 mm ± 55 mm
