7.4 Manufacturer-specific profiles; Idx 2000 to 6FFF
Parameters Index in object
directory
Default value
(factory preset)
Change saved
automatically
Change
effective
Config� channel 1 2000 01 0x01 (Bin IN)
adjustable after PreOp
Config� channel 2 2000 02 0x01 (Bin IN)
Config� channel 3 2000 03 0x01 (Bin IN)
Config� channel 4 2000 04 0x01 (Bin IN)
Config� channel 5 2000 05 0x03 (Ana IN absolute)
Config� channel 6 2000 06 0x03 (Ana IN absolute)
Config� channel 7 2000 07 0x02 (Bin OUT + read
back input)
Config� channel 8 2000 08 0x02 (Bin OUT + read
back input)
Config� channel 9 2000 09 0x01 (Bin IN)
Config� channel 10 2000 0A 0x01 (Bin IN)
Config� channel 11 2000 0B 0x01 (Bin IN)
Config� channel 12 2000 0C 0x01 (Bin IN)
Config� channel 13 2000 0D 0x03 (Ana IN absolute)
Config� channel 14 2000 0E 0x03 (Ana IN absolute)
Config� channel 15 2000 0F 0x02 (Bin OUT + read
back input)
Config� channel 16 2000 10 0x02 (Bin OUT + read
back input)
PWM frequency 2001 00 0x64 (100 Hz) adjustable after PreOp
Node ID * 20F0, 20F1 0x20 (0d32) yes after a reset
Baud rate * 20F2, 20F3 0x04 (125 Kbit/s) yes after a reset
Autostart 20F4 0x00 (Off) adjustable immediately
Entries in the object directory indexes 20F0/20F1 and/or 20F2/20F3 are only valid
if the rotary switches for baud rate and/or node ID are in the position “F”�
*) Observe rotary switch position!
