CabinetModule CR2012
7
5 Electrical connection
5.1 Connectors
The supply cables and inputs/outputs are connected via AMP crimp connectors on
the front of the device�









Pin connection (→ 8.4 Wiring)
You can find more information about the available connector accessories at:
www�ifm�com → Data sheet direct → CR2012 → Accessories
5.2 Fuses
► To protect the whole system (wiring and device) the individual electric circuits
must be protected with max� 8 A�
