IFM CR2012 - 11�2 Manufacturer-Specific Profiles; IDX 2000 to 6 FFF

UK
CabinetModule CR2012
25
11.2 Manufacturer-specific profiles; Idx 2000 to 6FFF
Index S-Idx Name Type Default Description
2000 0 number of IOs ro u8 0x10
1 configuration channel
1
rw u8 0x01 0x00 = off
0x01 = binary input
2 configuration channel
2
rw u8 0x01 0x00 = off
0x01 = binary input
3 configuration channel
3
rw u8 0x01 0x00 = off
0x01 = binary input
4 configuration channel
4
rw u8 0x01 0x00 = off
0x01 = binary input
5 configuration channel
5
rw u8 0x03 0x00 = off
0x01 = binary input
0x03 = analog input absolute
(voltage 0���10 V; 0x00���0xFF)
0x06 = analog input ratiometric
6 configuration channel
6
rw u8 0x03 0x00 = off
0x01 = binary input
0x03 = analog input absolute
(voltage 0���10 V; 0x00���0xFF)
0x06 = analog input ratiometric
7 configuration channel
7
rw u8 0x02 0x00 = off
0x01 = binary input
0x02 = binary output + read back
input
8 configuration channel
8
rw u8 0x02 0x00 = off
0x01 = binary input
0x02 = binary output + read back
input
0x04 = analogue output (PWM
20���250 Hz)
9 configuration channel
9
rw u8 0x01 0x00 = off
0x01 = binary input
A configuration channel
10
rw u8 0x01 0x00 = off
0x01 = binary input
B configuration channel
11
rw u8 0x01 0x00 = off
0x01 = binary input
C configuration channel
12
rw u8 0x01 0x00 = off
0x01 = binary input
D configuration channel
13
rw u8 0x03 0x00 = off
0x01 = binary input
0x03 = analog input absolute
(voltage 0���10 V; 0x00���0xFF)
0x06 = analog input ratiometric
