CabinetModule CR2012
28
Index S-Idx Name Type Default Description
2 user string 2 rw str 16 characters
6100 0 number of binary
inputs (16bit)
ro u8 0x01
1 binary inputs ro u8 - bits 0���15: binary inputs channel
1����16
6200 0 number of binary
outputs (8bit)
ro u8 0x01
1 binary outputs wo u8 0x00 0b0000 0001 = channel 7
0b0000 0010 = channel 8
0b0000 0100 = channel 15
0b0000 1000 = channel 16
6401 0 number of analogue
inputs
ro u8 0x04
1 analogue input
channel 5
ro s16 - for configuration absolute
measurement
-> 0x00���0xFF
for configuration ratiometric
measurement
-> -1000���0���+1000
2 analogue input
channel 6
ro s16 - (see above)
3 analogue input
channel 13
ro s16 - (see above)
4 analogue input
channel 14
ro s16 - (see above)
6414 0 number of analogue
outputs (ifm specific)
ro u8 0x02
1 analogue output
channel 8
wo u16 0x0000 0���1000 per mille
2 analogue output
channel 16
wo u16 0x0000 0���1000 per mille
