The IODDs necessary for the unit's configuration, detailed information about
process data structure, diagnostic information, parameter addresses and the
necessary information about required IO-Link hardware and software can be
found at www.ifm.com.
9 Parameter setting
The parameters of the unit can be set both via the inductive teach button and via
IO-Link. To be able to use all the functions of the unit, an IO-Link communication
is required.
9.1 Parameter setting with IO-Link
Using an IO-Link capable parameter setting tool, the following options are
available:
- Reading current process values.
- Reading, changing and saving current parameter settings and transmitting
them to other units of the same type.
► Connect the unit via the IO-Link interface to a PC or PLC with suitable
parameter setting software.
ifm offers an IO-Link interface for the connection of the sensor via USB
port.
9.2 Setting parameters via IO-Link
Parameters Description Setting range
TI Select Teach selection SSC1 / SSC2 / SSC3
default = SSC1
SSC Param SP1 Switch point 1 -180.0°...179.9°
Steps 0.1°
SSC Config Logic Switch point logic 0 High active (NO)
1 Low active (NC)
SSC Config Hyst Switch point hysteresis 0.1°...5°
SSC Tol Tolerance of the switching
channel 1
0.1°...15.0°
Pin 5 /gr assignment Functional assignment for pin
5 / grey
0 = open / 1 = close /
2 = seat / -32768 error
