3.1 Applications
Type of pressure: relative pressure
Order no. Measuring range
Permissible
overload pressure
*
)
Bursting pressure
bar PSI bar PSI bar PSI
Pressure sensors with G¼ internal thread
PN7160 0���600 0…8700 800 11580 2500 36250
PN7070 0���400 0…5800 800 11580 1700 24650
PN7071 0���250 0…3620 500 7250 1200 17400
PN7092** 0���100 0…1450 300 4350 650 9400
PN7093** 0���25 0…362 150 2175 350 5075
PN7094** -1���10 -14�5…145 75 1087 150 2175
PN7096 0���2�5 0…36�2 20 290 50 725
PN7097 0���1 0…14�5 10 145 30 450
PN7099 -1���1 -14�5���14�5 10 145 30 450
Pressure sensors with G¼ external thread
PN7560 0���600 0…8700 800 11580 2500 36250
PN7570 0���400 0…5800 800 11580 1700 24650
PN7571 0���250 0…3620 500 7250 1200 17400
PN7592** 0���100 0…1450 300 4350 650 9400
PN7593** 0���25 0…362 150 2175 350 5075
PN7594** -1���10 -14�5…145 75 1087 150 2175
PN7596 0���2�5 0…36�2 20 290 50 725
PN7597 0���1 0…14�5 10 145 30 450
PN7599 -1���1 -14�5���14�5 10 145 30 450
*
)
With static overload pressure or max� 100 million pressure cycles�
**
)
Use devices with a measuring range ≥ 250 bar for gas applications > 25 bar!
As an alternative, ifm’s PN7072 or PN7572 sensors can be used for gas applications for
a measuring range of 0���100 bar�
MPa = (measured value in bar) ÷ 10
kPa = (measured value in bar) x 100
