Plugging in for NBN or Fibre
Smart wiring
Some newer homes have internal smart wiring, allowing your NBN Connection Box to be plugged into a
patch panel in one room, and your modem to be plugged into the corresponding port on a patch panel
in another room.
NBN Connection
Box / Fibre Unit
Ethernet Cable
Power Button
Power Cable
Ethernet Cable
Power Socket
Plug into your
computer’s
Ethernet Port
(optional)
Handset for
Netphone
(optional)
