English
8
6. Connect a mixer, an amplifier or a PA system to the stereo line outputs. It is possible to control the output
volume with the DATA/VOLUME knob on the top panel (please refer to the instruction on this manual). These
are floating balanced output. This kind of output approximately simulates a floating transformer winding;
if both hot and cold outputs are driving signal lines, then the outputs are balanced, as if a centre- tapped
output transformer were being used. This system has the advantage that it can give the same level into
either a balanced or unbalanced input without rewiring connectors. These kind of outputs are also perfect to
route the onstage signal to a mixer without the need of a DI box, ensuring a loud and pristine signal.
7. Connect your headphones to the headphone output. It is possible to control the output volume with the
DATA/VOLUME knob on the top panel (please refer to the instruction on this manual).
1/4"
