IK Multimedia iRig Stomp I/O User Manual

English
10
3 Live Mode
3.1 Using iRig Stomp I/O with AmpliTube
When connected to a device running AmpliTube you can access to a full set of controls. Below we describe the
operational mode when the app/software AmpliTube is running.
USB MIDI port
Make sure to have selected “iRig Stomp IO Control” as MIDI IN/OUT port.
3.2 Preset mode
Switch combination Function MIDI message sent
Pressing Switch 3+4 >1sec. Stomp Mode/Preset Mode CC#39 val 0
MIDI CH 1
The iRig Stomp I/O has two main modes: Preset and Stomp. To switch between the two, simply press
simultaneously footswitches 3 and 4 for more than 1 second. When in Stomp mode, the LED on the top panel
will light up red.
Launch AmpliTube and tap on the LIVE section:
