ILMOR MV-10 - Electrical System - Engine Wiring Diagram

Owner’s Manual &
Installation Instructions
Revision 6e
Page 31
Electrical System - Engine Wiring
ASD SENSE
JTEC ECU
MARINE SPEC
FUEL PUMP
BATTERY
MARINE
STARTER
GAUGE OIL Psi
(RED/WHITE)
810
9
5
3
7
1
2
4
6
#8 #3 #2 #5
#10
#9 #6 #7 #4 #1
ASD RELAY
("+" GREEN/WHITE STRIPE)
("-" TAN)
FUEL PUMP
RELAY
STARTER
RELAY
(TO ENG. BLOCK)
-+
C
B
A
BATTERY "-"NEG
TACH, SIGNAL OUTPUT : 2.5 PULSE/REV
WATER TEMP, SIGNAL
ALARM, SIGNAL
ENGINE IGN., ON SIGNAL BATTERY "+"POS ENGINE STARTER, SIGNAL OIL PRESS, SIGNAL OIL TEMP, SIGNAL
1
2
3
8
7
4
5
6
10
ALARM
OIL Psi
ALARM
OIL TEMP.
ALARM-WATER
GAUGE-WATER
GAUGE
OIL TEMP
ECU PLUG COLOR CODE PLUG A=BLACK PLUG B=WHITE PLUG C=GRAY
Fuse 15
Fuse 20
Fuse 40
NEUTRAL SAFTEY
SWITCH
Fuse 15
IGN. COIL PACK
IGN. COIL PACK
FUEL INJECTORS
MARINE ALT.
FUSIBLE LINK
Circuit Breaker 50amp
G
= COMMON POINT GROUND
/INTAKE GROUND STUD
G
G
G
