ILMOR MV-10 - Electrical System - Sensor Layout

Owner’s Manual &
Installation Instructions
Revision 6e
Page 35
Electrical System - Sensor Layout
B
A
C
Fig. 21 Fig. 22
A – Oil Temp. Alarm
B – Water Temp. Alarm
C – Water Temp. Sender (Gauge)
Sensor Torques
See: "
Engine Fastener Torque Specifications, Sensor Torques”
