ILMOR MV-10 - Engine Fastener Torque Specifications (Continued); Sensor Torque Specifications

Owner’s Manual &
Installation Instructions
Revision 6e
Page 48
Engine Fastener Torque Specifications (continued)
Damper 130 ft lb (small bolt style)
250 ft lb (large bolt style)
Crank Pulley 17 ft lb
w/ blue loctite
3/8 NPT plug 18 ft lb w/ PST
1/8 NPT plug 95 in lb w/ PST
Drain Plug 18 ft lb
Cam Sensor 95 in lb
w/ blue loctite
Crank Sensor 95 in lb w/ blue loctite
Starter 30 ft lb w/ blue loctite
Alternator 30 ft lb w/ blue loctite
Idler Pulley 30 ft lb w/ blue loctite
Power Steering 17 ft lb w/ blue loctite
Sea Pump to Block 17 ft lb w/ blue loctite
Sea Pump Body 5/16-18 17 ft lb
10-24 60 in lb
w/ red loctite
Belt Tensioner 30 ft lb w/ blue loctite
Flywheel 75 ft lb w/ blue loctite
Drive Plate 35 ft lb w/ blue loctite
Spark Plugs 20 ft lb w/ anti-seize
Motor Mount to Block 30 ft lb w/ blue loctite
Bellhousing to motor 3/8-16 40 ft lb
w/ blue loctite
5/16-18 32 ft lb
w/ blue loctite
1/4-20 25 ft lb w/ blue loctite
Transmission to Bellhousing 40 ft lb
w/ blue loctite
Sensor Torques
Camshaft Position Sensor Screw 95 in lb
Crankshaft Position Sensor Screw 95 in lb
