Iluv iMM183 - Location of Controls on the Remote Control

GETTING STARTED
24. REMOTE CONTROL holder
25. EXT. Antenna jack
26. AUX IN Jack
27. ALERT OUT jack
28. Battery compartment
29. POWER Jack
Location of Controls on the Main Unit – CONTINUED
1. POWER AL OFF Button
2. UP Button
3. SKIP /AUTO SCAN Button
4. VOLUME +/- Button
5. iPod
Select Button
6. SNOOZE/DIMMER Button
7. MODE Button
8. SLEEP Button
9. MENU Button
10. SETUP Button
Location of Controls on the Remote Control
11. SELECT Button
12. SKIP /AUTO SCAN Button
13. DOWN Button
14. PLAY/PAUSE Button
15. iPod
Select Button
16. MUTE Button
17. BASS TREBLE Button
18. WEATHER/HAZARD Button
19. REPEAT Button
SNOOZE/DIMMER
VOL
MEMORY
AUTO
SCAN
AUTO
SCAN
SELECT
MODE MUTE
MENU
AL OFF
SETUP
SLEEP
BASS
TREBLE
WEATHER
HAZARD
REMOTE CONTROL
AUX IN DC 10V, 2AALERT OUTEXT. ANTENNA
1
2
3
4
5
6
7
8
10
11
12
14
15
16
17
18
9
13
19
24 26 2925
iLuv | 8iMM183 | V10M10_IM_EN_09092009
27 28
