4. Drill four holes in the marked locations
with four screws.
5.
Place the wall plate
against the surface and
fix it with screws M4.
6.
Fit the IMEON on the wall plate and verify
that the inverter is solidly fixed.
Tighten the
two M4 screws to the mounting bracket on
the bottom.
