3-3 Electrical connection
WARNING: To prevent the risk of electric shock, make sure that the ground cable is correctly
connected to the earth before switching on and using the inverter.
Connectors
Suggestion of cable
PV
PV +
A : + (MC4 type)
10AWG or 6mm
2
PV -
A : - (MC4 type)
Grid
L
B : L1 (RST)
N
B : N (RST)
Ground
E (RST)
Battery
BAT +
C : POS +
6AWG or 16mm
2
BAT -
C : NEG -
AC output
L
D : L (RST)
10AWG or 6mm
2
N
D : N (RST)
Ground
D : Grd (RST)
CAUTION: These values are provided solely for guidance. It is necessary to calculate again the
cable cross section, according to the current and to the used distance.
