Immarsat FB500 - CHAPTER 6. Composition of Equipment

6-5
CHAPTER 6. Composition of Equipment
The JUE-500 is composed of the following units;
Table6. Components of JUE-500
Name of component Type Q’ty
ADE
GSC-501 1
BDE GSC-502 1
JUE-500
Standard
Handset NQW-267 1
OIU NQA-2217 1
Option
GYRO I/F Box NQA-2066A 1
Overall view of components
Fig. 6b ADE (inside of Radome)
Fig. 6c Main unit
Fig. 6d Handset
Fig. 6f GYRO I/F Box
Fig. 6a ADE
A
ntenna Unit
A
DE
X axis Rate sensor
EL sensor
Y axis Rate sensor
Fig. 6e OIU
