Immergas EOLO Maior - Page 10

TECHNICIAN
INSTALLER
USER
9
DIAPHRAGM
Duct length in metres
Ø 60/100 horizontal
Ø 46
Ø 48
From 0 to 1
From 1 to 2
Over 2
NONE
DIAPHRAGM
Duct length in metres
Ø 60/100 vertical
Ø 46
Ø 48
From 0 to 2.7
From 2.7 to 3.7
NONE Over 3.7
DIAPHRAGM
*Duct length in metres
Ø 80 horizontal duct with two
bends
Ø 46
Ø 48
NONE
From 0 to 20
From 20 to 26
Over 26
DIAPHRAGM
Duct length in metres
Ø 80/125 horizontal
Ø 46
Ø 48
NONE
From 0 to 1.9
From 1.9 to 4.6
Over 4.6
DIAPHRAGM
Duct length in metres
Ø 80/125 vertical
Ø 46
Ø 48
From 0 to 6.8
From 6.8 to 9.5
NONE Over 9.5
DIAPHRAGM
*Duct length in metres
Ø 80 vertical duct without
bends
Ø 46
Ø 48
From 5 to 25
From 25 to 33
NONE Over 33
From 0 to 5
Ø 42,5
Eolo 21 Maior @ diaphragm table. Eolo 24 Maior @ diaphragm table.
DIAPHRAGM
Duct length in metres
Ø 60/100 horizontal
Ø 44
Ø 47
From 0 to 1
From 1 to 2
Over 2
NONE
DIAPHRAGM
Duct length in metres
Ø 60/100 vertical
Ø 44
Ø 47
From 0 to 2.7
From 2.7 to 3.7
NONE Over 3.7
DIAPHRAGM
Duct length in metres
Ø 80/125 horizontal
Ø 44
Ø 47
NONE
From 0 to 1.9
From 1.9 to 4.6
Over 4.6
DIAPHRAGM
Duct length in metres
Ø 80/125 vertical
Ø 44
Ø 47
From 0 to 6.8
From 6.8 to 9.5
NONE Over 9.5
DIAPHRAGM
*Duct length in metres
Ø 80 horizontal duct with two
bends
Ø 44
Ø 47
NONE
From 0 to 16
From 16 to 28
Over 28
DIAPHRAGM
*Duct length in metres
Ø 80 vertical duct without
bends
Ø 44
Ø 47
From 5 to 21
From 21 to 33
NONE Over 33
From 0 to 5
Ø 41,5
