Immergas EOLO STAR 24 3 E - Boiler Installation; Installation Recommendations

1-1
3 - IE
INSTALLATORUSERTECHNICIAN
1
BOILER INSTALLATION.
1.1 INSTALLATION
RECOMMENDATIONS.
e Eolo Star 24 3 boiler has been designed for
wall mounted installation or installation inside
the wall using the recessed frame provided; they
must be used to heat environments, to produce
hot water and similar purposes. In the case of
wall installation the wall surface must be smooth,
without any protrusions or recesses enabling
access to the rear part. ey are NOT designed
to be installed on plinths or oors (Fig. 1-1).
By varying the type of installation the classica-
tion of the boiler also varies, precisely:
- Indoor installation:
- without the 2 intake caps and with upper
casing. exhaust terminal Ø80 (conguration
type B
22
);
- without upper casing and with concentric
terminals and separators (conguration type
C).
- Outdoor installation in partially protected
areas:
- without the 2 intake caps and with upper
casing. Exhaust terminal Ø80 (conguration
type C);
- the upper casing is recommended but not
obligatory with concentric terminals and
separators (this conguration is also type C).
- Outdoor installation with recess frame:
- using the spacers under the side plugs of the
sealed chamber (conguration type C);
- leave the plugs of the sealed chamber
mounted and use the concentric pipes or
other types of pipes suitable for the sealed
chamber for air intake and fume exhaustion
(conguration type C).
Only professionally qualied heating/plumbing
technicians are authorised to install Immergas
gas appliances. Installation must be carried out
according to the standards, current legislation
and in compliance with local technical regu-
lations and the required technical procedures.
Installation of the Eolo star 24 3 E boiler when
powered by LPG must comply with the rules
regarding gases with a greater density than air
(remember, as an example, that it is prohibited to
install plants powered with the above-mentioned
gas in rooms where the oor is at a lower quota
that the average external country one). Before
installing the appliance, ensure that it is delive-
red in perfect condition; if in doubt, contact the
supplier immediately. Packing materials (staples,
nails, plastic bags, polystyrene foam, etc.) consti-
tute a hazard and must be kept out of the reach
of children. If the appliance is installed inside
or between cabinets, ensure sucient space for
normal servicing; therefore it is advisable to le-
ave clearance of at least 3 cm between the boiler
casing and the vertical sides of the cabinet. Leave
adequate space above the boiler for possible water
and fume removal connections.
Keep all ammable objects away from the ap-
pliance (paper, rags, plastic, polystyrene, etc.).
Do not place household appliances underneath
the boiler as they could be damaged if the sa-
fety valve intervenes (if not conveyed away by
a discharge funnel), or if there are leaks from
the hydraulic connections; on the contrary, the
manufacturer cannot be held responsible for
any damage caused to the household appliances.
In the event of malfunctions, faults or incorrect
operation, turn the appliance o immediately and
contact a qualied technician (e.g. the Immergas
Technical Aer-Sales Centre, which has speci-
cally trained sta and original spare parts) Do not
attempt to modify or repair the appliance alone.
Failure to comply with the above implies personal
responsibility and invalidates the warranty.
• Installation regulations: this boiler can be in-
stalled outdoors in a partially protected area.
A partially protected area is one in which the
appliance is not exposed to the direct action of
the weather (rain, snow, hail, etc...). If necessary
it is possible to install the boiler in positions
totally exposed to the direct action of the we-
ather using only the cover kit (Optional) e
boiler can be installed inside a wall using the
appropriate recessed frame (Optional).
Important: Wall mounting of the boiler on the
wall or inside the wall must guarantee stable
and efficient support for the generator. The
recessed frame kit (Optional) guarantees an
adequate support only if installed correctly (in
accordance with the code of practice) following
the instructions on the instruction leaet. e
recessed frame for the Eolo Star 24 3 E boiler is
not a supporting structure and must not replace
the wall removed. It is necessary to position the
boiler inside the wall. For safety reasons against
any leaks it is necessary to plaster the boiler
housing in the brick wall.
e plugs (standard supply) are to be used only in
conjunction with the mounting brackets or xing
template to x the appliance to the wall; they only
ensure adequate support if inserted correctly
(according to technical standards) in walls made
of solid or semi-hollow brick or block. In the
case of walls made from hollow brick or block,
partitions with limited static properties, or in any
case walls other than those indicated, a static test
must be carried out to ensure adequate support.
N.B.: the hex head screws supplied in the blister
pack are to be used exclusively to x the relative
mounting bracket to the wall.
ese boilers are used to heat water to below
boiling temperature in atmospheric pressure.
ey must be attached to a heating system sui-
table for their capacity and voltage.
YES NO
