3.22 SPARE PART LIST INTEC 30 SYSTEM EXTERNAL.
N. CODE DESCRIPTION
SERIAL NUMBER START OF
SERIES
-
3.025937
H
y
draulic group
-
3.026049
Control panel - complete
1
1.038189
D.8 pipe, hydraulic assembly - expansion tank
2
1.030996
Expansion vessel
(
8 litres
)
3
3.022550
Pump group
4
1.015258
1/2" F plug
5
1.028394
NTC probe
6 nfs Heat exchanger gasket 6
3.021695
Kit of O-rings multi-functions
7 nfs Outlet manifold clip 7
3.021696
Clip kit
8 nfs Pipe clip
(
d.18
)
8
3.021696
Clip kit
9
1.039282
Hex socket screw
(
M5x65
)
10
1.025910
Graphite gasket for burner
11
1.023442
Gas manifold cover
12
1.029156
D.18 pipe, water gas module - h
y
draulic group
13
1.029159
Condensation module - pump pipe
(
d.18
)
14
1.038529
Gas valve - manifold pipe
(
d.14
)
15
1.033901
A
ir intake pipe
16
1.027277
A
bsolute pressure switch
17
1.020211
Cord packing
18
1.026455
Red silicone O-ring
(
9,19x2,62
)
19
1.025357
Gas manifold cover gasket
20
1.033854
Epdm O-Ring
(
18,00x2,8, 83sh
)
21 1.0153 Crossheaded screw
(
M4x6
)
22
1.027178
Fan
23
1.026281
Burner
24
1.025690
Pressure point cap
25
3.026237
Subframe assembl
y
26
1.027108
Drain fitting
27
1.031531
D.14,2 plug
28
1.023992
Gasket
(
24x16x2
)
29
1.023578
Crossheaded screw
(
M5x25
)
30
1.023676
Gasket
(
d.80
)
31
1.032851
Filling pipe
(
d.8
)
32 nfs Pressure switch locking clip 32
3.021696
Clip kit
33
1.035250
Crossheaded self-tapping screw
(
3x16
)
34 1.1176 Crossheaded screw
(
M5x8
)
35 nfs Metal-sheet clip
(
d.9
)
35
3.021696
Clip kit
36
1.023581
Rubber adapter
37
1.034459
Crossheaded screw
(
M4x20
)
38 nfs Pump coupler fitting 38
3.021694
Two pump coupler fittings with o-ring kit
39
1.034173
Cap
40
1.025911
Nut
(
M6
)
41
3.026423
Front casing, assembl
y
42 1.4139 Crossheaded self-tapping screw
(
3.9x13
)
43
1.012468
Stainless steel elastic washer
(
M5
)
44
1.033429
M5x10 hex screw
45
1.034324
Seal painted cabinet assembl
y
's hole
46
2.015657
Pipes clamping plate
47 1.4072 Clip with clamp screw hole 48
1.038380
Brass pressure point
49 nfs Peroxide epdm O-Ring
(
17,86x2,62
)
49
3.021694
Two pump coupler fittings with o-ring kit
49
3.021695
Kit of O-rings multi-functions
50
1.034405
Gasket
(
18.5x11.5x2
)
51
1.036539
D.18 pipe b
y
pass
52
1.037089
Outlet c
y
linder manifold
53 1.7349 Crossheaded screw
(
M4x10
)
54
1.034614
Black silicone pipe
(
8x12
)
55 1.0017 Crossheaded screw
(
M6x12
)
56
1.024296 Flue probe with O-ring
57
1.030251
Ignition electrode gasket
58
2.014524
Module mount bracket
59
1.038379
Gas nozzle
(
d.6,90
)
60
1.021483
Silicone hood gasket
61
1.033902
Fan flange for pipe fixing
62
1.025278
Plug for flange with sample points
63 nfs
A
dhesive foam strip
(
d.10x3
)
63
3.026423
Front casing, assembl
y
64 nfs
A
dhesive foam strip
(
d.15x3
)
64
3.026423
Front casing, assembl
y
65
1.027009
Silicone fairlead
(
d.2
)
66 nfs Front casing 66
3.026423
Front casing, assembl
y
67
1.037994
Flange with sample points
68 2.015633 Lx-Rx wall, casing 69 1.019751 Silicone fairlead
(
d.6,5
)
70 1.031289 Knob 71 1.2268 3.68x1.78 O-ring, nitrile, 70 sh 72 1.036640 Nut
(
M4
)
73 nfs Front casing, seal 73 3.026423 Front casing, assembl
y
74 1.030666 Gasket for flange with sample points 75 nfs Clip 75 3.021696 Clip kit 76 1.010289 Tropicalized hex socket screw
(
M5x16
)
77 1.038389 PCB 78 3.026268 Bezel,control panel with nameplate
assembl
y
79 1.030300 Control panel back cover 80 1.026482 Manometer 81 1.037094 3/4'' M - 3/4'' M nipple 82 1.030301 Connection group cover 83 1.035248 Crossheaded self-tapping screw
(
3x10
)
84 1.034606 Ceramic glass
(
d.20
)
85 1.029694 Energy metering coupler fitting 3/4"
M-F
86 1.7908 Black cable clamp 87 1.038185 Sealed chamber gasket 88 1.028650 Return manifold 89 1.028643 Safet
y
valve
(
3 bar
)
90 1.030667 Condensate drain s
y
stem
91 1.025884 Stud M4 92 1.024898 Gasket for module inspection hole 93 2.013322 Flange for module cover inspection
hole
94 nfs Epdm O-Ring
(
2,57x1,78, 70 sh
)
94 3.021695 Kit of O-rings multi-functions 95 1.016246 Crossheaded self-forming screw
(
M4x8
)
96 1.030219 Cone pointed crossheaded self-
tapping screw
(
4,2x6,5
)
97 1.023334 Gas manifold 98 1.024543 Front ceramic fibre panel 99 1.025689 Gas manifold gasket
100 1.028548 Housing, outlet manifold 101 1.038187 Storage tank flow pipe
(
d.18
)
102 1.024204 Rubber buffer 103 1.6011 Crossheaded flat pointed self-tapping
screw
(
3,5x9,5
)
104 1.031823 SIT 848 gas valve 105 3.020367 Plastic siphon 106 1.2337 Crossheaded self-tapping screw
(
3,9x25
)
107 1.038188 Boiler return pipe
(
d.18
)
108 nfs Epdm O-Ring
(
13,94x2,62, 70 sh
)
108 3.021695 Kit of O-rings multi-functions 109 1.038336 Lowered brass nut
(
1/2''F
)
110 1.031448 Condensation module 111 nfs 19.8x3.6 O-ring 111 3.021695 Kit of O-rings multi-functions 112 3.021689 B
y
-pass complete cartridge
113 1.8599 Washer
(
4,3x12
)
114 1.024680 Burner gasket 115 1.022362 Peroxide epdm O-Ring
(
9,25x1,78
)
116 1.011163 Tropicalized washer
(
3,2x7x0,5
)
117 1.023993 Gasket
(
14.8x8x2
)
118 nfs Epdm O-Ring
(
7,6x2,62, 70 sh
)
118 3.021695 Kit of O-rings multi-functions 119 1.038337 Lowered brass nut
(
3/4''F
)
120 1.019654 Flexible hose for siphon 121 1.038018 Screen-printed plate 6 wa
y
122 1.5899 Wall plug package
(
d.10x50
)
123 1.025898 Flexible hose
(
l.200
)
124 1.028444 Nut for flexible hose 125 1.021452 Gasket for flexible hose 126 1.016967 Spring pipe clamp for silicone pipe
(
d.22
)
127 1.024387 "Y" hose union 128 1.024084 Crossheaded screw
(
M5x14
)
129 1.010500 Spring pipe clamp for silicone pipe
(
d.22
)
130 1.025797 Klixon thermostat 100°C 131 2.014456 Frame 132 1.028554 Pump bod
y
133 1.032431 Pump motor 134 2.015642 Valve supporting plate 135 1.038378 Venturi 136 1.7967 Crossheaded self-tapping screw
(
3.5x19
)
137 1.031572
A
djustment-hole plug
138 1.1656 Nickel-plated crosshead self-tapping
screw
(
3,5x6,4
)
139 1.038393 Gasket
(
28x21x1
)
140 1.024996 Brass pressure point 141 1.031009 5-way terminal block with fuse
housing
142 1.021762 NTC fast immersion probe 143 2.014706 Spark generator bracket 144 1.038394 Gasket
(
34x27x1
)
145 1.023554 Door hinge mount 146 nfs Front casing insulating panel 146 3.026423 Front casing, assembl
y
147 1.025360 Spark generator 148 1.038395 1/2" M - 3/8" M nipple 149 1.038349 Casing insulating panel 150 1.027016 Seal, sealed safet
y
valve
151 1.027110
A
utomatic vent valve
152 2.014014 Bracket for expansion vessel 153 1.031288 Control panel push-button 154 3.020380 Complete cartridge 155 1.034442
A
dhesive for displa
y
156 1.026460 Peroxide edpm O-Ring
(
44,12x2,62
)
157 1.2170 Crossheaded screw
(
M4x8
)
158 1.029697 Siphon tank 159 3.017477 Ignition electrode group 160 1.021892 Siphon plug 161 1.6984 Crossheaded flat pointed self-tapping
screw
(
2.9x9.5
)
162 1.030916 Grommet 163 1.038022 Screen-printed plate 164 1.031293 Screw fixing terminal block 165 1.6804 6-wa
y
terminal block
166 1.8532 Crossheaded self-tapping screw
(
3,9x16
)
167 1.034615 Black silicone pipe
(
4x8
)
168 1.032007 Detection electrode 169 1.011131 Fairlead
(
d.8
)
170 1.034610
A
nnealed copper washer
(
10x5,2x1
)
171 1.4246 Lock washer
(
M4
)
172 1.026530 Nitrile O-Ring
(
63x3 sh
)
173 1.6221 Hose union for silicone pipe 174 1.038478 Plug 175 1.037356
A
dhesive nameplate
176 1.4066 Self-tapping screw
(
3,5x9,5
)
177 2.015634 Casing cover 178 2.015635 Lx panel fixing plate 179 2.015636 Rx panel fixing plate 180 2.015638 Bracket bottom 181 3.026006 Painted cabinet assembl
y
little cover
182 1.011745 D.100 flue sealing collar 183 1.020366 Black peroxide epdm gasket
(
d.60
)
184 1.020370 Gasket
(
d.100
)
185 1.025710 Peroxide epdm gasket
(
d.100
)
186 3.020896 D.100-60 elbow assembl
y
187 3.024101
A
ir intake-drain terminal
188 3.026008 Front exterior casing, assembl
y
189 1.020369 D.60-100 shaped seal 190 1.2369 Crossheaded screw
(
M4x12
)
191 3.025397
A
dapter d.60-100 assembl
y
