26
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
1.16 CONCENTRIC VERTICAL KIT
INSTALLATION
Type C conguration, sealed chamber and fan assisted
Concentric vertical intake and exhaust kit.
is vertical terminal is connected directly to the outside of the
building for air intake and ue gas exhaust.
e vertical kit with aluminium tile enables installation
on terraces and roofs with a maximum slope of 45% (ap-
prox. 25°) and the height between the terminal cap and
half-shell (374 mm for Ø 60/100 and 260 mm for
Ø 80/125) must always be observed.
Mounting the vertical kit with aluminium tile
Ø60/100 (Fig.22)
1. Install the concentric ange (2) on the central hole of the boi-
ler, positioning gasket (1) with the circular projections
downwards in contact with the boiler ange.
2. Tighten the concentric ange with the screws in the kit.
3. Replace the tiles with the aluminium sheet (4), shaping it to
ensure that rainwater runs o.
4. Position the xed half-shell (6) on the aluminium tile.
5. Insert the intake-exhaust pipe (5).
6. Fit the Ø 60/100 concentric terminal pipe with the male side
(5) (smooth) into the ange (2) up to the end stop, making sure
that the wall sealing plate has been tted (3); this will ensure
sealing and joining of the elements making up the kit.
When the boiler is installed in areas where very cold
temperatures can be reached, a special anti-freeze kit is
available that can be installed as an alternative to the
standard kit.
C32
7
4
6
5
1
2
3
22
e kit includes (Fig. 22):
N o. 1 Gas ke t (1)
No.1 Female concentric ange (2)
No.1 Wall sealing plate (3)
No.1 Aluminium tile (4)
No.1 Intake/exhaust concentric pipe Ø 60/100 (5)
No.1 Fixed half-shell (6)
No.1 Mobile half-shell (7)
Extensions for Ø 60/100 vertical kit (Fig. 23)
e kit with this conguration can be extended to a max. straight
vertical length of 4.3 m, including the terminal.
is conguration corresponds to a resistance factor of 100.
In this case the special extensions must be requested.
C32
1
23
Key (Fig. C3223):
1 - Maximum length
