4.2 COMBUSTION PARAMETERS
Gas type G20 G31
Supply pressure mbar (mm H2O) 20 (204) 37 (377)
Gas nozzle diameter mm 0.82 0.48
Flue ow rate at D.H.W. nominal heat output kg/h (g/s) 47 (13.13) 50 (13.81)
Flue ow rate at heating nominal heat output kg/h (g/s) 5 0 (13. 81) 51 (14.14)
Flue ow rate at min heat output kg/h (g/s) 34.18 (9.85) 33.12 (10.01)
CO2 to nominal Q. % 7.3 (± 0,2) 7.9 (± 0,2)
CO2 to ignition Q. % 3.95 (± 0,2) 4.7 (± 0,2)
CO2 to minimum Q. % 3.95 (± 0,2) 4.7 (± 0,2)
CO with 0% O2 at Nom./Min. Q. ppm 121 / 25 92 / 38
NOx with 0% O2 at Nom./Min. Q. mg/kWh 55 / 25 42 / 26
Flue temperature at nominal output °C 70 69
Flue temperature at minimum output °C 70 67
Max air combustion temperature °C 50 50
Combustion parameters: measuring conditions of useful eciency (ow temperature/return temperature= 80 / 60 °C), ambient tempe-
rature reference = 15°C.
Concentric intake/exhaust available head
with
ue gas diaphragm Ø80
Concentric intake/exhaust available head
with
ue gas diaphragm Ø77
Concentric intake/exhaust
available head
without diaphragm
Pa Pa Pa
33 43 60
Ø80 exible intake/exhaust available head
with Ø45 ue diaphragm
Ø80 exible intake/exhaust available head
with Ø55 ue diaphragm
Pa Pa
24 80
