3.24 TECHNICAL DATA.
- e data relating to domestic hot water perfor-
mance refer to a dynamic inlet pressure of 2 bar
and an inlet temperature of 15°C; the values
are measured immediately at the boiler outlet,
considering that to obtain the data declared,
mixing with cold water is required.
- (*) Yields refer to the lower heating value.
Domestic hot water nominal heat input kW (kcal/h) 24,6 (21156)
Central heating nominal heat input kW (kcal/h) 21,3 (18318)
Minimum heat input kW (kcal/h) 3,1 (2630)
Domestic hot water nominal heat output (useful) kW (kcal/h) 23,6 (20296)
Central heating nominal heat output (useful) kW (kcal/h) 20,6 (17716)
Minimum heat output (useful) kW (kcal/h) 3,0 (2580)
(*) Eciency 80/60 Nom./Min. % 96,9 / 98,1
(*) Eciency 50/30 Nom./Min. % 101,2 / 108,6
(*) Eciency 40/30 Nom./Min. % 104,6 / 109,1
Casing losses with burner On/O (80-60°C) % 0,47 / 1,0
Heat loss at ue with burner On/O (80-60°C) % 0,01 / 2,4
Central heating circuit max. operating pressure bar 3
Maximum heating temperature °C 90
Adjustable heating temperature (max operation eld) °C 20 - 85
System expansion vessel total volume l 5,8
Expansion vessel factory-set pressure bar 1,0
Appliance water content l 1,9
Head available with 1000 l/h ow rate kPa (m H
2
O) 37,2 (3,8)
Hot water production useful heat output kW (kcal/h) 23,6 (20296)
Domestic hot water adjustable temperature °C 30 - 60
Domestic hot water circuit min. pressure (dynamic) bar 0,3
Domestic hot water circuit max. operating pressure bar 10
Flow rate capacity in continuous duty (∆T 30°C) l/min 12,2
Weight of full boiler kg 33,9
Weight of empty boiler kg 32,0
Electrical connection V/Hz 230 / 50
Nominal power absorption A 0,69
Installed electric power W 90
Pump absorbed power W 59
Fan power absorbed power W 22
Value EEI ≤ 0,20 - Part. 3
Equipment electrical system protection - IPX5D
Temperature of combustion products °C 75
NO
X
class - 5
Weighted NO
X
mg/kWh 28,0
Weighted CO mg/kWh 20,0
Type of appliance
C13 / C13x / C33 / C33x / C43 / C43x / C53 / C63 /
C83 / C93 / C93x / B23 / B33
Category II 2H3P

Immergas VICTRIX 24 TT 2 ERP Specifications

General

Brand	Immergas
Model	VICTRIX 24 TT 2 ERP
Category	Boiler
Language	English
