Analog input terminal sets the frequency. There are 2
standard analog input terminal, of which AI1 is adjusted
through digital potentiometer, AI2 (0~10V/0~20mA) this
is set by the jumper.
Note: when AI2 selects 0~20mA input, 20mA
corresponds to 10V.
100.0% of the analog input corresponds to P00.03,
-100.0% of the analog input corresponds to the reverse
P00.03.
6: Multi-stage speed running setting
The inverter runs at multi-stage speed mode when
P00.06=6 or P00.07=6. Set P05 to select the current
running stage, and set P10 to select the current running
frequency.
The multi-stage speed has the priority when P00.06 or
P00.07 does not equal to 6, but the setting stage can
only be the 1~15 stage. The setting stage is 1~15 if
P00.06 or P00.07 equals to 6.
7: PID control setting
The running mode of the inverter is process PID control
when P00.06=7 or P00.07=7. It is necessary to set P09.
The running frequency of the inverter is the value after
PID effect. See P09 for the detailed information of the
preset source, preset value, feed-back source of PID.
8:MODBUS communication setting
The frequency is set by MODBUS communication. See
P14 for detailed information.
Note: A frequency and B frequency can not set as the
same frequency reference method.
