iDrive2 inverters Function Parameters
35
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P05.03
S3 terminals
function
selection
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10:Increasing frequency setting(UP)
11:Decreasing frequency setting(DOWN)
12:Cancel the frequency change setting
13:Shift between A setting and B setting
14:Shift between combination setting and A setting
15:Shift between combination setting and B setting
16:Multi-stage speed terminal 1
17:Multi-stage speed terminal 2
18:Multi-stage speed terminal 3
19:Multi- stage speed terminal 4
20:Multi- stage speed pause
21:ACC/DEC time option 1
25:PID control pause
26:Traverse Pause(stop at the current frequency)
27:Traverse reset(return to the center frequency)
28:Counter reset
30:ACC/DEC prohibition
31:Counter trigger
33:Cancel the frequency change setting temporarily
34:DC brake
36:Shift the command to the keypad
37:Shift the command to the terminals
38:Shift the command to the communication
7
◎
P05.04
S4 terminals
function
selection
0
◎
P05.05
S5 terminals
function
selection
0
◎
