iDrive2 inverters Function Parameters
43
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P07.04
STOP/RST
stop function
Select the stop function by STOP/RST. STOP/RST is
valid in any state for the fault reset.
0:Only valid for the panel control
1:Valid for both panel and terminals control
2:Valid for both panel and communication control
3:Valid for all control modes
0
○
P07.05
The
parameter
selection1 of
running state
0x0000~0xFFFF
BIT0:running frequency (Hz on)
BIT1:set frequency(Hz flickering)
BIT2:bus voltage (Hz on)
BIT3:output voltage(V on)
BIT4:output current(A on)
BIT5:running rotation speed (rpm on)
BIT6:output power(% on)
BIT7:output torque(% on)
BIT8:PID reference(% flickering)
BIT9:PID feedback value(% on)
BIT10:input terminals state
BIT11:output terminals state
BIT12:torque set value(% on)
BIT13:pulse counter value
BIT14:length value
BIT15:current stage in multi-stage speed
0x03FF
○
P07.06
The
parameter
selection 2 of
running state
0x0000~0xFFFF
BIT0: analog AI1 value (V on)
BIT1: analog AI2 value (V on)
BIT4: motor overload percentage (% on)
BIT5: the inverter overload percentage (% on)
BIT6: ramp frequency reference value(Hz on)
BIT7: linear speed
0x0000
P07.07
The
parameter
selection of
the stop state
0x0000~0xFFFF
BIT0:set frequency(Hz on, frequency flickering slowly)
BIT1:bus voltage (V on)
BIT2:input terminals state
BIT3:output terminals state
BIT4:PID reference (% flickering)
BIT5:PID feedback value(% on)
BIT7:analog AI1 value(V on)
0x00FF
○
