iDrive2 inverters Function Parameters
63
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P17 Group Monitoring function
P17.00
Set
frequency
Display current set frequency of the inverter
Range: 0.00Hz~P00.03
0.00Hz
●
P17.01
Output
frequency
Display current output frequency of the inverter
Range: 0.00Hz~P00.03
0.00Hz
●
P17.02
Ramp
reference
frequency
Display current ramp reference frequency of the inverter
Range: 0.00Hz~P00.03
0.00Hz
●
P17.03
Output
voltage
Display current output voltage of the inverter
Range: 0~1200V
0V
●
P17.04
Output
current
Display current output current of the inverter
Range: 0.0~5000.0A
0.0A
●
P17.05
The rotation
speed of the
motor
Display the rotation speed of the motor.
Range: 0~65535RPM
0 RPM
●
P17.08
Motor power
Display current power of the motor.
Setting range: -300.0%~300.0%(the rated current of the
motor)
0.0%
●
P17.09
Output
torque
Display the current output torque of the inverter.
Range: -250.0~250.0%
0.0%
●
P17.11
DC bus
voltage
Display current DC bus voltage of the inverter
Range: 0.0~2000.0V
0V
●
P17.12
Switch input
terminals
state
Display current Switch input terminals state of the
inverter
Range: 0000~00FF
0
●
P17.13
Switch output
terminals
state
Display current Switch output terminals state of the
inverter
Range: 0000~000F
0
●
P17.14
Digital
adjustment
Display the adjustment through the keypad of the
inverter.
Range : 0.00Hz~P00.03
0.00V
●
P17.18
Counting
value
Display the current counting number of the inverter.
Range: 0~65535
0
●
