IMO iDrive2 XKL - Page 64

iDrive2 inverters Function Parameters
64
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P17.19
AI1 input
voltage
Display analog AI1 input signal
Range: 0.00~10.00V
0.00V
●
P17.20
AI2 input
voltage
Display analog AI2 input signal
Range: 0.00~10.00V
0.00V
●
P17.21
AI3 input
voltage
Display analog AI2 input signal
Range: -10.00~10.00V
0.00V
●
P17.22
HDI input
frequency
Display HDI input frequency
Range: 0.00~50.00kHz
0.00 kHz
●
P17.23
PID
reference
value
Display PID reference value
Range: -100.0~100.0%
0.0%
●
P17.24
PID
response
value
Display PID response value
Range: -100.0~100.0%
0.0%
●
P17.25
Power factor
of the motor
Display the current power factor of the motor
Range: -1.00~1.00
●
P17.26
Current
running time
Display the current running time of the inverter.
Range:0~65535min
0m
●
P17.27
Current
stage of the
multi-stage
speed
Display simple PLC and the current stage of the
multi-stage speed
Range: 0~15
0
●
P17.36
Output
torque
Display the output torque. Positive value is in the
electromotion state, and negative is in the power
generating state.
Range : -3000.0Nm~3000.0Nm
0
●
P17.37
Counting
value of
motor
overload
0~100 (100: OL1)
●
