www.impro.net Impro Biometric Reader – Installation Manual Page 5 of 25
IBR Specifications
The IBR is a networked biometric/RFID reader
Door controller functionality (relay, Door Position Sense and Request to Exit and OSDP) will be included in a future release.
RFID, only models
HBR912 & HBR913
Protocol 13.56 MHz MIFARE/DESFire/DESFire EV1 /NFC/iClass/SEOS
RFID Read Range MIFARE/DESFire/EM/iClass/ISO15693 > 20 mm
Fingerprint
Image dimension 272 x 320 pixels
Image bit depth 8bit, 256 grayscale
Resolution 500 dpi
Template TBD / ISO 19794-2 / ANSI 378
Extractor / Matcher MINEX certified and compliant
Template on card Supported on SEOS cards (2 templates per card)
Live Finger Detection Supported
Capacity
Max. User (HBR910, HBR912) 1 000
Max. User (HBR911, HBR913) 5 000
Max. Template 10 per Tagholder (person)
Max. Text Log 1 000 000
General
CPU 1.2 GHz Quad Core
Memory 2GB DDR3 RAM + 8GB eMMC
RTC backup supply Super Capacitor keeps clock running ~10 days with no power
Operating Temperature -20°C to +66°C
Storage Temperature -40°C to +80°C
Operating Humidity 0% - 95%, non-condensing, at +40°C
Dimensions (L x W x D) 222 mm x 50 mm x 59 mm
Weight 380 g
IP Rating IP67
IK Rating IK08
Certificates CE
Interface
Ethernet Supported (10/100 Mbps)
Light Bar RGB
Sound Buzzer, Single volume, single tone, 4 kHz piezo-electric
*RS485 (OSDP) 1ch Master / Slave
Wiegand 1ch Input / Output
*TTL inputs 2 channels, 1 supervised
*Relay 1 relay: COM, NO & NC
Tamper Supported (Optical)
Electrical
Power 12 VDC, 2A peak, ~ 1A continuous
*TTL input levels VIH Min. 3V; Max. 5V
*TTL input pull-up
Internal resistive pull-up 4.7 k
Wiegand Output VOH > 4.8 V, VOL > 0.2 V
Wiegand Output Pull-up
Internal resistive pull-up 1 k
*Relay JRC-23FHS 1A/30V
DC
, 0.3A/60V
DC
, 0,5A/125V
AC
*The greyed items are reserved for a future revision of the product.
