www.impro.net Impro Biometric Reader – Installation Manual Page 8 of 25

Power Supply Connection

Power Supply considerations

 The IBR can draw up to 2A at 12VDC, and a separate 12VDC mains adaptor is recommended.

 Do NOT attempt to power the IBR from a Wiegand Reader terminal.

Network Connection

Connecting to an Ethernet Switch

Direct connection to a PC

Power +12V (Red)

Power Ground (Black)

12V DC

Power Supply

IBR

Switch

IBR
