Impulse RT750

─ 25 ─
Parts List and Exploded View
USB PCB ASSY
Fan Assembly
Item No.
Grade No. Part No. Description QTY
1 7.5.5.1 RT7505500 Holder For USB PCB 1
2 7.5.5.2 B152 USB PCB 1
3 7.5.5.3 GB845ST2.9*9.5DS Phillip Screw ST2.9*9.5 3
Item No.
Grade No. Part No. Description QTY
1 1.7.1 P07 Fan 1
2 1.7.2 GB818M4*40DS2 Phillip Screw M4*40 2
3 1.7.3 GB41M4DS2 Nut M4 2
4 1.7.4 RT7504400 Bracket For Fan 1
