IMT 3203i Parts & Specifications

Specications 4 Section - 2
3203i - Manual # 99904380
3203i Technical Data
GENERAL SPECIFICATIONS
CRANE RATING (crane rating (ft-lb) is the rated load (lb)
multiplied by the respective distance (ft) from centerline
of rotation with all extensions retracted and lower boom in
horizontal position.)
12,000 ft-lb at 7’-6” (1.6 tm at 2.3 m)
Horizontal Reach (From Centerline Of Rotation) 15’-0” (4.6 m)
Hydraulic Extension (1) 48” (122 cm)
Manual Extension (1) 48” (122 cm)
Lifting Height (From Base of Crane to Centerline of Sheave) 16’-2” (4.9 m)
Crane Weight (1H1m) 635 lb (288 kg)
Crane Storage Height 29” (73.7 cm)
Mounting Space Required (Crane Base) 14” x 18” (35.5 cm x 45.7 cm)
Hydraulic System Operating Pressure 2500 psi (172 Bar)
Maximum Hydraulic Flow 1.6 gpm (6 L/pm)
Oil Reservoir Capacity 1.5 gallons (5.7 L)
Oil Type O VG32, low pour, anti-wear hydraulic oil
CENTER OF GRAVITY
Horizontal from Centerline of Rotation (Booms Retracted) 22.88” (58.1 cm)
Horizontal from Centerline of Rotation (Booms Extended) 22.88” (58.1 cm)
Vertical from Bottom of Crane Base 12.75” (32.4 cm)
Tie-Down Bolt Pattern (On Center)
12” x 12” or 11.5” x 14.75”
(30.5 cm x 30.5 cm) or (29.2 cm x 37.5 cm)
Rotation Torque 2500 ft-lb (3.4 kN-m)
CYLINDER SPECIFICATIONS
Lower Boom Cylinder
2.75” bore; 16” stroke
(7 cm bore; 40.6 cm stroke)
Extension Boom Cylinder
1.5” bore; 48” stroke
(3.8 cm bore; 122.0 cm stroke)
WINCH SPECIFICATIONS
Winch Pull Line 2000 lb (907 kg)
Pull Line Speed Without Load 23 ft/min (7 m/min)
Rope Diameter 7/32” (5.56 mm)
Wire Rope Length 65’ (19.81 m)
Cable Nominal Strength 5600 lb (2540 kg)
PERFORMANCE CHARACTERISTICS
SPECIFICATIONS SPEED
Rotation 360º (Continuous) 44 seconds
Lower Boom Elevation -5º to +75º 10 seconds
Extension Cylinder 48” (122.0 cm) 10 seconds total
