IMT 3203i Parts & Specifications

Specications 11 Crane Reference
3203i - Manual # 99904380
3203i Recommended Spare Parts List
51721267 LOWER CYLINDER QTY.
51744137 SEAL KIT-IMT 2.75B 1.75R 1.50 S 1
60127432 PISTON-2.75 BORE X 1.75 ROD 1.63 STGR 1
60127434 HEAD-2.75 BORE X 1.75 ROD 1
73054999 VALVE-COUNTERBALANCE 1
77041786 SWITCH-PRESS 2750 PSI 1
51722111 EXTENSION CYLINDER
94397290 SEAL KIT-IMT 1.50 BORE 1.00 ROD .75 1
60135105 HEAD-1.50 BORE X 1.00 ROD 1
60135106 PISTON-1.50 BORE X .75 STGR 1
73054999 VALVE-COUNTERBALANCE SUN01 CBBC-LHN 1
99904315 BASE & MAST ASSEMBLY
60118032 CABLE CONNECTOR MODIFICATION 1
72601931 CAP SCREW .44-14X 3.00 HH 156 KSI PROOF L 16
73511156 MOTOR-HYDRAULIC 101 1035 009 1
76039295 GASKET-GEAR 1
77441534 SWITCH- 225A CONTACTOR (12 OR 24V) 1
77441281 CABLE CONNECTOR-FEMALE 1
77441285 TERMINAL RING, INSULATED 3/8 STUD
73734304 VALVE BANK (12V)
73540327 COIL (VALVE BANK) (12V) 3
73540326 VALVE ASSEMBLY (VALVE & COIL) (12V) 6
73734375 VALVE BANK (24V)
77040527 COIL (VALVE BANK) (24V) 3
73540336 VALVE ASSEMBLY (VALVE & COIL) (24V) 6
73511283 POWER UNIT (12V)
70733826 FILL CAP ELECTRIC CRANES 1
73511171 PUMP-GEAR ELECTRIC CRANE 1
73540323 VALVE-RELIEF ELECTRIC CRANE 1
73734332 KIT-TUBE POWER UNIT ELECTRIC CRANE 1
74397392 RESERVOIR TANK ELECTRIC CRANE 1
77043060 MOTOR-POWER UNIT ELECTRIC CRANE 1
73511305 POWER UNIT (24V)
77043066 MOTOR (24V) 1
73511306 PUMP 1
73540517 RELIEF VALVE ASSEMBLY 1
74399495 RESERVOIR 1
70734788 BREATHER CAP 1
73734791 TUBE-SUCTION 1
70734792 STRAINER 1

IMT 3203i Specifications

General

Brand	IMT
Model	3203i
Category	Construction Equipment
Language	English
