IMT 3203i Parts & Specifications

Specications 12 Crane Reference
3203i - Manual # 99904380
99904316 BOOM ASSEMBLY QTY.
60030373 WEAR PAD- EXT CYLINDER 1
60030374 WEAR PAD-ROUND 1.00 DIA X .50 DIA X .75L 6
60030375 WEAR PAD-ROUND 3.00 DIA X 1.00 DIA X .55L 1
60030376 WEAR PAD-ROUND 3.50 X 1.00 DIA X .615 LG 2
60132302 STOP SCREW 3/8-24 X .50 4
71734311 PIN-QUICK RELEASE.62D/4.5 CRIT 1
71734314 PIN-QUICK RELEASE.62D/6.5 CRIT 1
72661543 PIN-QUICK 316-10QP 2
60030372 SHEAVE- 5.5 NYLATRON 2
60133938 WEAR PAD-ROUND 0.25 X 1.00 X 0.50 X 0.50 2
72661711 CLEVIS PIN 0.5 X 3.00 1
60030483 SHEAVE-8.0 NYLATRON 1
99904317 CRANE & WINCH ASSEMBLY
51721494 CORD REEL ASSEMBLY- 5FT PACKARD CONNECTOR 1
70580059 WIRE ROPE ASM-.22(7X19)X65FT PGA 1
71413185 SPRING-.105WIRE 0.75OD 2.875 LG 1
70735101 HOOK-SWVL POS LOCK BBRG 2TON (EFFECTIVE 1/1/2018) 1
72601798 WASHER-LOCK 12MM 4
72601935 CAP SCREW M12-1.75X 40 SH PLAIN 4
72601938 BOLT-EYE # 8-32X 1.125 1
77041459 SWITCH-LIMIT ZE-N-2S 1
77441096 CONNECTOR- .50 STR RLF .25-.38 1
71570922 WINCH (12V)
77041801 CONTACTOR (12 OR 24V) 1
77566638 BRAKE ASSEMBLY 1
77744175 BRUSH KIT 1
71570922 WINCH (24V)
77041928 CONTACTOR (12 OR 24V) 1
77566638 BRAKE ASSEMBLY 1
77744175 BRUSH KIT 1
99904394 ELECTRICAL INSTALLATION
77441116 FUSEHOLDER, HIGH AMP 1
77441219 FUSE-225 AMP 1

IMT 3203i Specifications

General

Brand	IMT
Model	3203i
Category	Construction Equipment
Language	English
