IMT 3203i - Page 35

Parts 29 Section 4
3203i - Manual # 99904380
99904315 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QT Y.
1. 51721267 CYL- 2.75B X 1.75R X 16.06S 46.50 CC C 1
2. 51721319 KIT-HRDW 3203 BASE & MAST ASY 1
3. 51721664 CABLE ASM- 1GA-5/16RNGX 1/4RNGX 48.00LG 2 1
4. 51721943 CABLE ASM- 1GA-3/8RNGX SWVL FX 11.00LG 2 1
5. 51721944 CABLE ASM- 1GA-3/8RNGX SWVL MX 60.00LG 2 1
6. 51725663 KIT-HYD 3203I 1
7. 52725030 MAST WELDMENT-3203I 1
8. 52725036 WLDMT-BASE 3203I 1
9. 60132385 SPACER- POWER UNIT 1
10. 60140618 PIN-TYPE NN 1.00 X 8.25 1
11. 60140637 SHROUD- TURNTABLE GEAR 3203I 1
12. 60140642 BRKT-3203-4004 VLV MNT 1
13. 60141128 PLATE-ELEC ROTATOR BRKT BOTTOM 1
14. 60141129 PLATE-ELEC ROTATOR BRKT TOP 1
15. 70034382 CAP-GREASE PRO20 GC-RED 1 5
16. 70580194 CLAMP-I” CONDUIT HANGER W/BOLT 2
17. 71056678 GEAR-TRNTBL BRG S7C-73HA-25.4ML-DC104 1
18. 71415014 KEEPER-PIN .38 1
19. 72060000 CAP SCR .25-20X .50 HH GR5 Z 1 4
20. 72060002 CAP SCR .25-20X .75 HH GR5 Z 1 5
21. 72060004 CAP SCR .25-20X 1.00 HH GR5 Z 1 3
22. 72060021 CAP SCR .31-18X .50 HH GR5 Z 1 2
23. 72060044 CAP SCR .38-16X .75 HH GR5 Z 1 1
24. 72060046 CAP SCR .38-16X 1.00 HH GR5 Z 1 1
25. 72060048 CAP SCR .38-16X 1.50 HH GR5 Z 1 2
26. 72060051 CAP SCR .38-16X 2.25 HH GR5 Z 2
27. 72062103 NUT .38-16 HEX NYLOCK 1 2
28. 72062104 NUT .25-20 HEX NYLOCK 1 3
29. 72062107 NUT .50-13 HEX CENTER LOCK Z 1 2
30. 72062207 NUT 8-32 HEX NYLOCK 1 4
31. 72063001 WASHER .25 FLAT 1 11
32. 72063003 WASHER .38 FLAT 1 4
33. 72063049 WASHER .25 LOCK 1 9
34. 72063050 WASHER .31 LOCK 1 2
35. 72063051 WASHER .38 LOCK 1 4
36. 72063053 WASHER .50 LOCK 1 2
37. 72063132 WASHER .50 FLAT ASTM F436 1 20
38. 72063271 WASHER # 8 W FLAT ANSI B27.2Z 1 4
39. 72531130 ELBOW-STREET STL .12 X 90 DEG 3 1
40. 72534418 ZERK-NPT .12 X 1.75 LG 1 1
41. 72601932 CAP SCR .50-13X 4.00 SH ZC 1 13
42. 72601939 CAP SCR .50-13X 4.50 SH ZC 1 2
43. 72601949 CAP SCR .50-13X 1.25 SH ZC 1 2
44. 72602009 SCR-MACH # 8-32X 1.25 BTNHD SS 1 4
45. 72602081 CAP SCR .50-13X 3.00 SH ZINC 1 16
