IMT 3203i Parts & Specifications

Parts 34 Section 4
3203i - Manual # 99904380
99904315 COMPLETE PARTS LIST
ITEM NO. PART NO. DESCRIPTION QT Y.
46. 73511156 MOTOR-HYD 101 1035 009 1
47. 73511283 POWER UNIT- 1.19CC 12VDC 1
48. 73734304 VALVE BANK-3 SEC SERIES 3GPM @ 500PSI 12V 1
49. 73734375 VALVE BANK- 3 SEC SERIES3GPM 3000PSI 24V 1
50. 76039295 GASKET-GEA19 008-10056-1 1
51. 77441312 CABLE ASM-10GA-#10RNGX 1/4RNGX 6.00LG 1
52. 77441534 SWITCH-225A CONTACTOR 12V OR 24V 1
53. 91722219 KIT- 3203I ELECTRICAL INSTALLATION 1
53. 73511432 POWER UNIT- 0.61 GPM 201 MTE 1
REV. U CN885
WARNING
DO NOT CONNECT ELECTRICAL POWER
TO CRANE UNTIL ALL CONNECTIONS
HAVE BEEN TESTED. SEVER INJURY
COULD RESULT. ATTACH ELECTRICAL
WIRES AND GROUNDS TO COMPO-
NENTS BEFORE CONNECTING TO MAST.

IMT 3203i Specifications

General

Brand	IMT
Model	3203i
Category	Construction Equipment
Language	English
