Parts 39 Section 4
3203i - Manual # 99904380
51721267 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 51744137 SEAL KIT-2.75 B 1.75 R 1.50 S 20 1
2. 52721303 CASE ASM- 2.75 BORE X 26.98 LG 20 1
3. 52721304 ROD ASM-1.75 DIA X 28.81 LG 1.50 S 20 1
4. 60127432 PISTON- 2.75 BORE X 1.75 ROD 1.50 STGR 20 1
5. 60127434 HEAD- 2.75 BORE X 1.75 ROD 20 1
6. 6C175017 STOP TUBE-1.75 ROD X 1.75 LONG 20 1
7. 72062305 COLLAR-LOCK 1.50-12 THREADED 1-PC 20 1
8. 60138273 STOP TUBE-1.75 ROD X 0.25 LONG 20 1
9. 7T2NX420 WEAR RING-ROD 1.75 ID X 0.50 W 1 2
10. 76396596 WEAR RING-PISTON 2.75 OD X 0.75W 1 2
11. 76396597 SEAL- ROD 1.75 OD DZ 1 1
12. 76396598 PISTON SEAL-DYNAMIC 2.75IN CP 1 1
13. 7Q072222 O RING 1.50X 1.75X .12 70 1 1
14. 7Q072332 O RING 2.38X 2.75X .19 70 1 1
15. 7Q10P332 BACKUP RING-2.38 ID X 2.75 OD 1 1
16. 7R14P017 ROD WIPER - TYPE D 1.75 ROD 1 1
17. 60125699 PIN - LOCK TUBE 0.19 OD X 0.065 WALL 1 1
19. 77041786 SWITCH-PRESS 2750 PSI NC 42IN LEAD 1
20. 51721267A CYL-2.7/1.7 16.06S 30.44CC C 1
21. 73054999 VALVE-CBAL SUN01 CBBC-LHN 2 1
REV. E
CYLINDER DATA
EXTEND: 5.94 SQ IN X 0.413 GAL DRY WEIGHT: 58 LBS
RE T R AC T: 2.41 SQ IN X 0.246 GAL BRG. SPAN: 16.9 %
CASE: 3.25 OD X 2.75B X 27.19LG TEST PSI: 3000 PSI
ROD: 1.75X28.81LG OPER. PSI: 2500 PSI
STINGER: 1.50X3.92LG
PISTON TORQUE: 710-740 PSI
HEAD TORQUE: 275 FT-LB
CYL. STROKE: 16.06” CARTRIDGE TORQUE: 30-35 FT-LB
LOCKNUT TORQUE: 12 FT-LB CAP SCR TORQUE: 16 FT-LB
